Ferrowave Micro

On Metal labels

ESD On Metal Label

UHF RFID / Dimensions 80 x 35 x 1,2 mm

Designed to be usable on any surface but optimized for ESD plastic that is generally a challenge for RFID tags. With the optional protective layer covering the printing ESD On Metal Label offers a new level of durability against chemicals and washing.

On Metal labels

Ferrowave Classic

UHF RFID / Dimensions 100 x 17 x 1,1 mm

Ferrowave Classic is optimized for the packaging and component tracking applications that don't need the most robust industrial structure but are more cost sensitive. Cost-engineered on metal label structure offers a solution for different needs from tagging automotive components to consumer packages with hard-to-tag metallic foils and liquid containers.

On Metal labels

Ferrowave Flag

UHF RFID / Dimensions 46 x 21 x 0,2 mm

Ferrowave Flag is versatile on metal label with excellent read range of up to 12 meters globally. Flag structure is optimized for easy attachment on challenging metallic parts while cost engineered materials enable item-level tracking. Ferrowave Flag comes with VDA compliant M4E IC specifically suitable for automotive parts tracking as well as other industrial applications.

Specialty labels

On Metal labels

Heatwave Flag Printable

UHF RFID / Antenna 72 x 8,5 mm

Printable variant of Heatwave Flag enables more flexibility for the installation process. Heatwave Flag Printable comes printer-ready, perforated on reel. Special white surface material is tested to be compliant with standard thermal transfer RFID printers while also offering protection against temperatures up to 260°C.

On Metal labels

Silverline Blade II

UHF RFID / Dimensions 60 x 25 x 1,4 mm

Despite the small footprint Silverline Blade II boasts a respectable 10 meter (33 ft) read range on metal. Even though being optimized on metal Blade works also on plastic and liquid containers. Industrial grade adhesive is having very high initial tack, meaning short curing time. This makes Silverline Blade II optimal solution for industrial and IT asset tracking as well as healthcare equipment.

On Metal labels

Silverline Blade II+

UHF RFID / Dimensions 60 x 25 x 1,4 mm

Silverline Blade II+ offers global tuning for applications requiring readability worldwide. With M780 IC, Blade II+ also enables higher memory for applications such as Automotive where standardized encoding schemes are used. Blade II+ is optimized for metal surfaces with up to 7m (23ft) read range but works also well on plastic and liquid containers. Blade II+ offers the same high tack adhesive as standard Blade II.

On Metal labels

Silverline Classic II

UHF RFID / Dimensions 100 x 40 x 1,3 mm

The original on metal label in the RFID industry. Biggest size in Silverline family offers the exceptional performance (up to 15 m / 50 ft) and large area for the printed information. The performance, durable PET face and industrial adhesive optimized for metallic surfaces makes Silverline Classic II also an option for metallic containers.

On Metal labels

Silverline Micro II

UHF RFID / Dimensions 45 x 13 x 1,3 mm

Smallest option in the Silverline family. With footprint of only 45 x 13 mm Silverline Micro II enables reliable tracking of even smallest of assets, from IT and enterprise assets to healthcare equipment and tools. Adhesive is optimized for metallic and painted metal surfaces.

On Metal labels

Silverline Slim II

UHF RFID / Dimensions 100 x 13 x 1,3 mm

Slim form factor combined with excellent performance is a choice for assets on which the suitable label width is more limited, for example applications involving smaller industrial assets, pipes and electronics. With patent-pending antenna design Silverline Slim II offers well balanced performance on different materials. Adhesive is optimized for metallic and painted metal surfaces.

On Metal labels

Steelwave Flex

UHF RFID / Dimensions 55 x 25 x 2,2 mm

Flexible on-metal label with extremely strong adhesive. Due to unique more flexible structure compared to other on-metal labels in the market Steelwave Flex is optimal solution to tag small components and assets. Flex is optimized for metal surfaces but do work also on plastics and liquid containers. Steelwave Flex comes with VDA encoding scheme compliant IC by default.

On Metal labels

Steelwave HF

NFC / Antenna 22 x 22 mm

Steelwave HF 25x25mm is a flexible NFC and HF RFID label option for metallic assets. With its industrial grade materials Steelwave HF is a reliable solution for more harsh manufacturing environment. Steelwave HF is available with NTAG213 and SLIX2 to offer a solution for both ISO 14443 and ISO 15693 applications.

On Metal labels

Ferrowave Micro

UHF RFID / Dimensions 45 x 8 x 1,5 mm

Ferrowave Micro on metal label boasts a small footprint and optimal read performance to manage specialty retail items that can be most challenging to track with standard RFID tags. Ferrowave Micro is optimized for item-level high volume tracking of specialty retail categories such as sports equipment, beauty and personal care items and also serves as brand authentication for high value goods.
